WESTWIND Trailer
WT264
SPECIFICATIONS
| Length |
27' 10" |
|
8.5 m |
| Height |
8' 11" |
|
2.7 m |
| Width |
8' 0" |
|
2.4 m |
| Dry Hitch Weight |
595 lbs |
|
270 kg |
| Dry Axle Weight |
4343 lbs |
|
1970 kg |
| Dry Total Weight |
4938 lbs |
|
2240 kg |
| GVWR |
6500 lbs |
|
2948 kg |
| Cargo Capacity |
1562 lbs |
|
709 kg |
| Tire Size |
|
ST225/75R15 |
|
| Propane Tanks |
|
2 x 20 lbs |
|
| Liquid Waste Capacity |
28 US gal |
|
106 L |
| Solid Waste Capacity |
37 US gal |
|
140 L |
| Water Heater Capacity |
6 US gal |
|
23 L |
| Water Tank Capacity |
46 US gal |
|
174 L |
| Water System Capacity |
52 US gal |
|
197 L |
| Entrance Door Width |
30" |
|
76 cm |
| Fridge Capacity |
6 cu ft |
|
170 L |
| Furnace Output |
|
25000 BTU |
|
| STANDARD
FEATURES |
CHASSIS
"Atwood" 2000 lb. Front
Crank Jack
"Standen's"
Running Gear
Metal Mud Flaps
Tubular Steel Frame with
Integral Water & Holding
Tanks
CONSTRUCTION
"Fome-Cor" Double Insulation
3/8" Fir Plywood Roof Decking
with 7 Year Warranty
5/8" Fir Plywood Floor Decking
with 7 Year Warranty
Double-screwed Lumbercore
Cabinet Frames
Residential Style Vapor
Barrier in Ceiling
Solid Oak Mortise and Tenon
Cabinet Doors
Truss Roof System Complete
with Rubber Roof
EXTERIOR
.024 Gauge Aluminum Siding
A&E "Sunchaser" Patio
Awning
Automotive Undercoating
Fender Skirts
Insulated Luggage Doors
with Easy Open Pull Tabs
R.V. Leveling Guides
Radius Corner Tinted Safety
Glass Windows
Roadside Service Light
Rubber Rockguard
Spare Tire and Carrier
APPLIANCES
"Atwood" D.S.I. Water
Heater
"Wedgewood" Oven
with High-output Burner
& Stove Cover
Auto Change-over LP Regulator
B.B.Q. Propane Fitting
Coffee Maker
Large "Hydroflame" Forced-air
Furnace
Large 2-door Refrigerator
Power Range Hood with Monitor
Panel
INTERIOR
Bunk Bed or Full Bed Divider
Drape
Bunk Bed Shelves
Coordinated Bedspread, Pillows
and Shams on Full Beds
Decorative Vinyl Wall Panel
Durable Kitchen Counter
Top Laminate
Fiberglass Double Kitchen
Sink and Cover
Metal Venetian Blinds in
Kitchen and Living Area
Oak Trimmed Medicine Cabinet
Roll-up Blinds in Main Bedroom
Spring Filled Mattress on
Full Beds
SYSTEMS
110 Volt Converter with
5 Amp Battery Charger
110V GFI Protected Patio
Receptacle
Battery Disconnect Switch
Exterior Cable Hook-up System
Large Capacity Water System
LP Gas Detector and Smoke
Detector
Polyetheylene Holding Tanks
Power Roof Vent in Bathroom
Pre-wire for Solar Panel
Pre-wire for TV Antenna
Single-pedal Foot Flush
Toilet "Bravura by Thetford"
Water Heater Bypass Valves
|
OPTIONS
"Starbrite" Aluminum Rockguard,
Mud Flaps & Bumper Cover
30# LP Tanks & Cover
Accumulator Tank
Bunk Cargo Door
CD Stereo System
Decor Toss Cushions
Electric Front Hitch Jack
Exterior Shower
Fantastic Fan - Bathroom
Fantastic Fan - Bedroom
Fantastic Fan - Living Area
Large Assist Handle
Microwave
Power Roof Vent - Bedroom
Power Roof Vent - Living
Area
Roof Air (non-ducted) w/Heat
| | | | | |
